Product Features
-
Multi-layer nanofiber membrane (5 layers or more) delivers ultra-high filtration efficiency of over 99% while providing larger dirt-holding capacity.
-
High-density pleated design combines large filtration area, high flow rate, long service life, and high contaminant capacity.
-
Optimized integrated polyester outer support ensures greater strength and enhanced pressure resistance.
-
Unique O-ring design provides superior sealing performance.
-
Glass fiber reinforced end caps increase overall cartridge durability.
-
Wide micron range: 0.5–100 μm, suitable for various filtration levels.
-
Flexible length specifications: 20″, 40″, 60″.
-
Easy and quick cartridge replacement, saving significant labor and time.
Technical Specifications
Size (Diameter × Length) Design Flow Rate (m³/h) Max. Flow Rate (m³/h) Filtration Area (m²) 7″ × 20″ 15 40 3.3 7″ × 40″ 30 80 6.5 7″ × 60″ 45 110 8.5 Material Construction
Component LFC Version Filter Media PBT Support / Drainage Layer PBT End Cap PBT Outer Protective Net PBT Operating Characteristics
Parameter Value Maximum Operating Temperature 120°C Maximum Differential Pressure 0.38 MPa @ 20°C Recommended Change-out Pressure 0.15 MPa @ 20°C Typical Applications
-
Filtration of chemical condensates
-
Steam condensate in power plant heating networks
-
Hydrogen peroxide production workshops
-
High-temperature liquid filtration
-
Precision filtration of aromatic hydrocarbon solutions such as benzene, toluene, etc.
-
